Size and Weight

Width
(mm)

Thickness (mm)

Width
(inch)

Thickness
(inch)

Weight
Kgs/Ft
38 3 1 ½ 1/8 0.30
38 5 1 ½ 3/16 0.40
38 6 1 ½ 1/4 0.50
38 8 1 ½ 5/16 0.60
38 9 1 ½ 3/8 0.80
38 12 1 ½ 1/2 1.20
50 5 2 3/16 0.60
50 6 2 1/4 0.75
50 8 2 5/16 0.90
50 9 2 3/8 1.15
50 12 2 1/2 1.55
50 21 2 3/4 1.80
50 25 2 1 2.00
63 5 2 ½ 3/16 0.80
63 6 2 ½ 1/4 0.90
63 8 2 ½ 5/16 1.20
63 9 2 ½ 3/8 1.40
63 12 2 ½ 1/2 1.90
63 21 2 ½ 3/4 3.10
63 25 2 ½ 1 3.85
75 5 3 3/16 1.40
75 6 3 1/4 1.55
75 8 3 5/16 1.65
75 9 3 3/8 1.90
75 12 3 1/2 2.30
75 21 3 3/4 3.40
88 25 3 1 4.60
88 6 3 ½ 1/4 2.70
88 8 3 ½ 5/16 3.30
88 9 3 ½ 3/8 3.90
88 12 3 ½ 1/2 4.70
88 21 3 ½ 3/4 5.00
88 25 3 ½ 1 5.25
100 6 4 1/4 2.90
100 8 4 5/16 3.60
100 9 4 3/8 4.10
100 12 4 1/2 5.00
100 21 4 3/4 5.40
100 25 4 1 5.80
125 8 5 3/8 3.60
125 12 5 1/2 3.90
125 21 5 3/4 4.80
125 25 5 1 5.60
150 8 6 3/8 5.70
150 12 6 1/2 5.90
150 21 6 3/4 6.25
150 25 6 1 6.80
